Summary:
The CX61XXBX series is a low-power high-voltage regulator based on CMOS technology, with good characteristics of low voltage difference and low static current. This series of chips allows a maximum input voltage of 6.5V and can be output.
Provide several fixed voltages within the range of 1.2V to 5.0V.
CX61XXBX chip has built-in overcurrent protection circuit, which can ensure job security and service life.
Characteristic:
Low input power consumption
Input withstand voltage: 6.5V
Low static current: 6.0uA
High output current: 300mA
External CE enable pin
Integrated overcurrent protection circuit
High output accuracy: ± 2%
Output voltage: 1.8V/3.0V/3.3V/3.6V
Application:
Battery powered equipment
Communication equipment
Consumer electronic devices
Audio/Video Devices
Power supply system for household appliances
Portable computer power supply system
Overview<br/>The CX78GD032E is a quasi-resonant flyback power conversion chip with integrated D-GaN, designed for isolated flyback switching power supplies targeting high performance, low standby power, low cost, and high efficiency within 48W.<br/> ...
Overview<br/>The CX78GD048H is a quasi-resonant flyback power conversion chip with integrated D-GaN, designed for isolated flyback switching power supplies targeting high performance, low standby power, low cost, and high efficiency within 36W.<br/> ...
Overview<br/>The CX75GD080BL is a high-frequency, high-performance quasi-resonant AC-DC power switch with an integrated high-voltage GaNFET power device. It is designed for isolated flyback switching power supplies targeting high performance, low sta...
Overview
The CX8831CQ is a synchronous buck converter with multiple integrated fast charging protocols. It supports USB Type-C and PD3.2 protocols, including PPS, Qualcomm QC2.0/3.0/3.0+, Huawei FCP/SCP/HVSCP, VOOC, MediaTek PE2.0, Samsung ...
Overview
The CX8836 is a four-switch synchronous buck-boost control IC featuring a wide input voltage range of DC 4.5V to 40V and a wide output voltage range of DC 3V to 25V.
The CX8836 employs current-mode control in both buck and boost operation...
Overview<br/><br/>The CX8360 is a 30V/6A DC-DC buck converter with integrated dual N-channel power transistors. It employs an advanced COT architecture, enabling the chip to deliver high-performance load response and input voltage regulation capability.&lt;b...
Overview<br/>The CX8560 is a wide-input voltage switching buck DC-DC converter capable of operating in either CV (constant voltage) or CC (constant current) mode. It features a maximum input voltage rating of 66V and operates within an input voltage range...
Overview
The CX78GD024E is a quasi-resonant flyback power conversion chip with integrated D-GaN, designed for isolated flyback switching power supplies targeting high performance, low standby power, low cost, and high efficiency within 68W.
...
Overview
The CX7806 is a quasi-resonant flyback power control chip with a built-in 14mR NMOSFET driver for D-GaN, designed for applications up to 68W.
Under no-load, light-load, or heavy-load conditions, the CX7806 automatically switche...
