Summary:
CX66XXAX series is a high input voltage (60V). A linear regulator with low static current and high PSRR. (LDO), capable of providing a load current of 150mA.
The characteristic of CX66XXAX is its fast response to line voltage and load current transients. The response to line voltage and load current transients is very fast, and it ensures that there is no overshoot voltage during LDO startup and short circuit recovery. During the short circuit recovery period, there was no overvoltage.
CX66XXAX has integrated short circuit and thermal shutdown protection. This device can provide fixed output voltages of 3.0V, 3.3V, 3.6V, and 5.0V, and is packaged with SOT23 and SOT89.
Characteristic:
Low static current: 2uA
High rated input voltage: up to 80V
Output current: 150mA
High PSRR: 70dB at 1Khz
Dropout voltage: 70mV@10mA
70mV@10mA
700mV@100mA
Fixed output voltage
3.0V, 3.3V, 3.6V, and 5.0V
High precision output voltage: ± 2%.
Good transient response
Integrated short-circuit protection
Integrated thermal protection
Application:
Battery powered equipment
Smoke detectors and sensors
Microcontroller applications
Household Electric Appliances
