QC protocol
HOME>PRODUCTS>Fast charging protocol chip>QC protocol

  • 型 号 :

    CX601

  • 保护功能 :

    OVP/UVLO/OCP/OTP etc

  • 内置MOS Rds(on) :

    QC3.0 protocol

  • 支持协议 :

    FCP, AFC, QC3.0/QC2.0 fast charging protocols

  • 典型应用 :

    Car charging, power supply, battery plug

  • 封 装 :

    SOT23-6
样品申领
产品规格书下载

CATEGORY
  • 产品详情

Overview:

QC3.0/FCP/AFC fast charging protocol controller recommendation CX601

CX601 is a USB port fast charging protocol control chip. Intelligent recognition of multiple fast charging protocols for fast charging of mobile phones and other powered devices. CX601 can accurately adjust the VBUS output voltage based on the voltage request sent by the receiving device, thereby achieving fast charging.

CX601 will automatically detect whether the connected device supports the Apple Fast Charge Protocol before adjusting the 5V output voltage. If supported, Apple devices will charge at maximum current. If not, it will continue to check if it supports the voltage regulation fast charging protocol. If the connected device does not support the voltage regulation fast charging protocol, CX601 will prohibit output voltage adjustment and configure the power supply device as USB DCP to ensure the safety of the powered device and obtain maximum current charging. If the voltage regulation fast charging protocol is supported, start accepting request instructions for output voltage adjustment.

CX601 can pass QC_ EN enables or disables the high-voltage fast charging function, making applications more flexible.


Features:

  • Supports Huawei FCP fast charging protocol

  • Supports Samsung AFC fast charging protocol

  • Supports Qualcomm QC3.0/QC2.0 fast charging protocol

  • Supports USB DCP with 2.7V voltage loading on D+and D -

  • Can provide a maximum charging current of 2.4A for Apple devices

  • Complies with USB BC1.2 protocol and supports USB DCP short circuiting of D+and D-

  • Complies with China Telecom Industry Standard YD/T 1591-2009

  • Supports short circuiting of D+and D-

  • Automatically switch applicable protocols for access devices

  • SOT23-6 Package


Applications:

  • Adapter

  • Car charger

  • Other USB port chargers

  • portable source
